Rapid Turnaround Precision Prototyping Machining Services For Electric Vehicles
| Place of Origin | China |
|---|---|
| Brand Name | Precision CNC Machining Titanium parts |
| Certification | ISO9001 Certificate of quality system/16949 |
| Model Number | Ti-6Al-4V |
| Minimum Order Quantity | 1 piece |
| Price | USD 20-100 pieces,negotiable |
| Packaging Details | Use boxes made of corrugated cardboard,Wrap with bubbles facing inward or Custom wooden cases larger than 25KG. |
| Delivery Time | 2-5 works day |
| Payment Terms | T/T, Western Union,Paypal |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material Capabilities | Titanium (6Al-4V)、Ti-2Al-2.5Zr、Ti-32Mo、Ti-Mo-Ni、Ti-Pd、SP-700、Ti-6242、Ti-10-5-3、Ti-1023、BT9 ，Customizable | Surface Treatment | Electroplated , Powder Coated , Black Coating. |
|---|---|---|---|
| Process Way | CNC Turning, CNC Milling, Cnc Machining Process | Tolerance | 0.01-0.05mm.based On Your Requests |
| Lead Time | 5-8 Days, Beased On Your Quantity. | Drawing Format | IGS, STEP, STL An So On. |
| Name | Titanium CNC Machining | MOQ | 1 Piece And Can Be Customized. |
| High Light | Rapid Turnaround Precision Prototyping Machining,Precision Prototyping Machining Services |
||
Product Description
Rapid Turnaround Precision Prototyping Machining Services For Electric Vehicles
Titanium is very strong and boasts a high strength-to-weight ratio. It also has excellent corrosion resistance,
high operating temperatures (up to 1,000°F) and is nontoxic. Machining titanium will be more costly than other metals
such as aluminum due to it being more hard to manufacture and machine.
In terms of appearance, titanium’s color varies depending on how much it has been altered.
It can range from dull gray in raw form to shiny silver when smooth.
- Tolerances down to ±0.0004″ (0.01mm)
- ISO 9001:2015 certiified
- 24/7 engineering support
Titanium Machining Applications
Titanium has range of applications due to its advanced material properties.
Frequently, you’ll find titanium parts in the aerospace, medical, military and marine industries.
- Compressor blades
- Discs
- Airframe and space capsule components
- Surgical equipment
- Pressure vessels
CNC Machining Titanium is Tough! Here are Some Tips and Top Alloys.
Luckily, expert machinists and tooling suppliers have come up with a few key ways to make machining titanium
at least a little bit easier.
3 Useful Tips for Machining Titanium:
Tip 1 – Use the Right Tool
With the growing popularity of titanium, tool designers are coming up with unique solutions for improving the machinability of titanium.
Advanced materials, like heat-resistant titanium aluminum nitride (TiAlN) or titanium carbo-nitride (TiCN) coated tooling, can extend tool
lifetimes. Meanwhile tooling with uneven spacing between cutting edges can disrupt the constructive interference that leads to tool chatter.
Tip 2 – Stabilize Your Setup
Titanium is already prone to causing tool chatter, so anything you can do reduce vibration will make machining titanium easier.
Ensure parts are well-supported and secured to prevent deflection in the workpiece. Use high-quality CNC machines with very stiff tooling arrangements. You can even consider using shorter cutting tools to reduce tool deflection.
Tip 3 – Adjust Cutting Parameters
Machining titanium requires careful temperature management. One of the most obvious ways to keep the workpiece and
tooling cool is to apply consistent, high-pressure coolant directed to the cut area. Blasting the chips out of the cut area also
keeps them from adhering to your machining tools.
|
|
|
| An alloy with a host of unique properties, titanium is often an optimal choice for CNC machined parts with specialized applications. Titanium has an impressive strength-to-weight ratio and is 40% lighter than steel while being only 5% weaker. This makes it perfect for high-tech industries like aerospace, automotive, medical technology and energy. The titanium machining process involves milling down a raw piece of metal into a desired part or component. | We offer a complete titanium CNC machining service and can produce custom titanium parts in Titanium Grade 1, Titanium Grade 2 and Titanium Grade 5. Titanium parts are corrosion resistant, quite durable, have a high melting point and are very versatile. We includes almost every kind of CNC mill and turning center, and is able to machine whatever you need, from simple, ‘as-machined’ workholdings to complex, organic geometries with tight tolerances. |
Why Choose Us
We are specializes in reliable aerospace part prototyping and production, ranging from simple to complex projects.
We combine manufacturing expertise with advanced technologies and adherence to quality requirements to bring your ideas to life.
|
Strong Manufacturing Capabilities
|
Get fast Quotation
|
Tight Tolerance Aerospace Parts
|
Fast lead Time
|
| As an ISO 9001-2015 certified manufacturing company, We can provide production line features advanced technologies to ensure manufacturing accuracy and precision. | We have a professional engineering team, can serve you 24 hours, as soon as we receive your drawings, we will provide a quote to you within one hour. | We can machine aerospace parts with tight tolerances up to +/-0.001 inches. We implement ISO 2768-m standard tolerance for metals and ISO-2768-c for plastics. | Parts within days, you can reduce cycle times. A perfect combination of advanced technologies and experience helps us deliver superior-quality aerospace parts with faster lead times. |
Our Quality ensure system
Payment method
Shipping method
Frequently asked questions
How to CNC titanium? |
|
|
|
|
Our workshop
Package way:
Frequently asked questions
How to CNC titanium? |
|
|
|
|
JYH is your Titanium CNC Machining best partner!
