ABS PC Plastic Injection Moulded Components Etched Texture Surface
| Place of Origin | China |
|---|---|
| Brand Name | low volume manufacturing |
| Certification | ISO9001 Certificate of quality system/16949 |
| Model Number | Customized |
| Minimum Order Quantity | 100 piece |
| Price | USD 5-100 pieces,negotiable |
| Packaging Details | 1.Use boxes made of corrugated cardboard,Wrap with bubbles facing inward or Custom wooden cases larger than 25KG. 2.Custom blister box. |
| Delivery Time | 10-30 works day |
| Payment Terms | T/T, Western Union,Paypal |
| Supply Ability | 100000 piecs one weeks |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Surface Treatment | Polishing. Etched. Texture, Painting, Texture, Electroplating | Product | Medical Product, Vehicle Mould, CUSTOM MACHINERY PLASTIC PART |
|---|---|---|---|
| Material | ABS, PP, Acrylic, Plastic POM And PC And Can Be Customized | Shaping Mode | Plastic Injection Moulding |
| Mould Life | As Client Custom, 100000-1000000 Shots | Color | As Your Required |
| High Light | PC Plastic Injection Moulded Components,ABS Plastic Injection Moulded Components,injection molding mold parts Etched |
||
Product Description
Plastic Injection Molding Services For Mold Plastic Black ABS+PC Mold Products
Injection Molding Service
Custom injection molding services for plastic prototypes and start the production parts at JYH.
Get a free injection molding quotation and design feedback within 1 hours.
►Rapid Tooling Production as fast as 2 weeks
►ISO 9001:2015 certified
►24/7 engineering support
Injection Moulding Process:
Plastic injection moulding allows to produce large numbers of parts with great accuracy and A quick cycle times from multi-cavity tools. The process of injection mould involves a certain amount of polymer materials being heated, melted, and injected into a mould under high pressure. Further into the process, main units of the injection moulding machine are:
- feed hopper;
- heated barrel;
- crew (known as the injection unit);
- clamp unit (which holds the mould together under the injection pressures);
- ejection unit (which removes the part from the mould).
Plastic Material Comparison Chart
|
Material |
Approximate Tensile Strength |
Impact Strength |
Electrical Insulation |
Temperature Resistance |
Chemical Resistance |
FDA Compliant |
Cost (low to high) |
|
Acrylic (PMMA) |
8200 psi |
low |
no |
high |
strong |
no |
medium |
|
Acrylonitrile Butadiene Styrene (ABS) |
5800 psi |
high |
no |
low |
medium |
no |
medium |
|
Nylon Polyamide (PA12) |
12500 psi |
high |
yes |
high |
strong |
yes |
high |
|
Polycarbonate (PC) |
9700 psi |
high |
no |
high |
weak |
yes (can contain bisphenol A, or BPA) |
high |
|
Polyethylene (PE) |
1300 psi (LDPE) |
high (LDPE) |
yes |
low |
strong (LDPE) |
yes |
low |
|
Polyoxymethylene (POM) |
6400 – 10600 psi |
high |
yes |
high |
strong |
yes |
high |
|
Polypropylene (PP) |
4900 psi |
medium |
yes |
medium |
strong |
yes |
low |
|
Polystyrene (PS) |
2570 – 7690 psi |
high |
no |
|
medium |
yes |
low |
|
Thermoplastic Elastomer (TPE) |
280 – 8100 psi |
high |
no |
low |
strong |
no |
high |
Our Injection Molding Capabilities
Plastic Injection Molds
With our experience and advanced machinery, we excel at designing and manufacturing a series of plastic injection molds adjusted to your tolerance and cost.
Plastic Injection Molding
Our plastic injection molding process uses precise machinery to shoot molten resin into a mold to become a final production-grade thermoplastic part.
Amorphous vs Semi-crystalline Thermoplastics:
There are two types of thermoplastic materials that we commonly use at Integrated Molding Solutions,
amorphous and semicrystalline. Amorphous thermoplastic material can be highly transparent and
has good formability with a lower melting temperature range. While amorphous thermoplastics have
poor chemical resistance, this provides an easier bond to other materials using adhesives or solvents.
Amorphous and Semi-crystalline thermoplastic material comparison chart:
| Amorphous Thermoplastics | Semi-crystalline Thermoplastics |
| Soften over a wide temperature range | Sharp melting point |
| Good formability | Poor form ability |
| Transparency | Opaque |
| Poor chemical resistance | Good chemical resistance |
| Bonds well using adhesives or solvents | Difficult to bond using adhesives or solvents |
| Prone to stress cracking | Resistant to stress cracking |
| Poor fatigue resistance | Good fatigue resistance |
| Structural applications only | Good for bearing and wear |
| Acrylic, PC, ABS, PS | LDPE, HDPE, PP, PET |
QC checking before ship the product:
Payment term:
Shipping way:
After service:
FAQ:
Here are concise responses to your FAQs:
Project Progress: We'll keep you updated via email or calls.
Mold Lead Time: Depends on complexity.
3D Printing Prototypes: Ready within [insert time] after design approval.
Confidentiality: Your drawings remain private, not used for our gain.
Product Quality: If unsatisfied, we'll collaborate on solutions.
OEM & ODM: We offer both options for your convenience.
Our Identity: We are a [insert your description, e.g., "leading manufacturer"].
Design Assistance: Our team can refine or create designs for you.
Getting a Quote: Share details for a detailed project quote.
Assembly & Packaging: We provide assembly and custom packaging.
Price Information: Contact us for accurate pricing details.
Custom Injection Molding Services For Plastic Prototypes And Production Parts,JYH is your best injection mold supplier!
Injection Moulding is highly repeatab.
